631 Stainless steel tube manufacturer

631 is China's 0Cr17Ni7Al, 631 is semi-austenitic precipitation hardening stainless steel, is a kind of austenitic unstable stainless steel, this steel solid solution state, at room temperature for austenite structure, after cold processing, cold treatment or heating to about 750 degrees for adjustment treatment, austenite can be transformed into martensite, and then aging treatment,
The second phase can be precipitated on the martensite matrix to strengthen the steel.

631 Stainless steel tube Price in China ,Manufacturer of 631 Stainless Steel tube

Standard: GB/T 1220-2007
631 is China's 0Cr17Ni7Al, 631 is semi-austenitic precipitation hardening stainless steel, is a kind of austenitic unstable stainless steel, this steel solid solution state, at room temperature for austenite structure, after cold processing, cold treatment or heating to about 750 degrees for adjustment treatment, austenite can be transformed into martensite, and then aging treatment,
The second phase can be precipitated on the martensite matrix to strengthen the steel.
The function of Al is to form precipitation hardening phases such as (Ni3Al) with other elements.
In the aging process, cooling can not be carried out rapidly, otherwise it is difficult to achieve strengthening effect.

1) Solid solution, fast cooling at 1000 ~ 1100℃;
2) Aged at 565℃, after solid solution treatment, kept at 760±15℃ for 90min, cooled to below 15℃ for 30min within 1h, then heated to 565±10℃ for 90min, then cooled by air;
3) Aged at 510℃, after solid solution treatment, kept at 955±10℃ for 10min, cooled to room temperature for less than 24h to -73±6℃ for 8h, then heated to 510±10℃ for 60min, air cooled.
Click to Request Information >

Equivalent Material of 631 Stainless Steel  tube

Grade Euronorm China GB Japanese JIS
No.
631 1.4568 0Cr17Ni7Al SUS631

Standard Specification Of 631 tube

Thickness 0.5mm-100mm
Outer diameter 10mm, 25.4mm, 38.1mm, 50.8mm, 100mm, 250mm, 300mm, 350mm, etc
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Finish Hot rolled  (HR), Cold rolled Tube (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form Round tube Square tube Rectangular tube etc.

631 stainless steel composition content.

Grade C Mn Si P S Cr Mo Ni Cu Al
631 Min.
Max.
≤0.09 ≤1.00 ≤1.00 ≤0.035 ≤0.03 16.00~18.00 / 6.50~7.75 ≤0.50 0.75~1.50

Tensile strength σb (MPa) : solid solution,≤1030;
565 ℃ ageing, p 1140;
510 ℃, 1230 or more
Confined yield strength σ0.2 (MPa) : solid solution,≤380;
565 ℃ ageing, p 960;
510 ℃ ageing, p. 1030
Elongation Δ5 (%) : solid solution,≥20;
565 ℃ ageing, 5 or more;
510 ℃ ageing, 4 or more
Section shrinkage ψ (%) : 565℃ aging,≥25;
510 ℃ ageing, 10 or more
Hardness: solid solution,≤229HB;
363 hb 565 ℃ ageing, p;
510 ℃ ageing, p 388 hb

Common Types Of 631 Stainless steel tube

  • 631 Stainless steel tube

  • 631 Stainless steel tube

  • 631 Stainless steel tube

Dimensions Standard,weight chart and size schedules of 631 stainless steel Tube

SS 631 Tube Size(mm) SS631 Tube Weight per Unit Area(kg/m)
6*1 0.125
6*1.5 0.168
8*1 0.174
8*1.5 0.243
10*1 0.224
10*1.5 0.318
12*1 0.274
12*1.5 0.392
12*2 0.498
14*1 0.324
14*2 0.598
14*3 0.822
16*2 0.697
16*3 0.971
17*3 1.046
18*1 0.423
18*1.5 0.617
18*2 0.797
18*3 1.121
20*1 0.473
20*2 0.897
20*3 1.27
21*3 1.345
22*2 0.996
22*2.5 1.214

Price list

Stainless Steel 631 tube Price List 631tube FOB Shanghai Per Unit (USD)
2mm 631 stainless steel tube $2500.00-$3000.00
ss 631 mirror Stainless Steel Coil/ Strip/ tube $2800.00-$3300.00
631 Stainless Steel tube / Stainless Steel tube 631 $2500.00-$3000.00
Standard size metal sus 631 grade stainless steel tube prices $2500.00-$3000.00
